Flux Coated Mma Electrode For Cutting All Metals Ferrous And Non-Ferrous
NSP
CLASSIFICATION
NO NATIONAL SPECIFICATIONS
PRODUCT DESCRIPTION
A high iron oxide flux, very low in conventional minerals that produces a highly oxidising gas plasma around the arc initiated by the core wire. The flux is extruded onto the core wire using special silicates to maintain coating strength during electrode usage.
WELDING FEATURES OF THE ELECTRODE
The electrode functions AC and DC producing a strong arc accompanied by a highly oxidizing gas plasma. It is necessary to start cutting action at the edge of plate. Once started the metal is cut by an oxidizing action and the gravitational removal of the molten or cooling resultant oxides.
APPLICATIONS AND MATERIALS TO BE WELDED
Cutting all metals without specialised equipment up to 15mm thick. Particularly useful on site. No slag remains, only sintered iron oxide particles which are only lightly attached, not fused, to the plate surface. The cut edges and sub-surface do not suffer any carbon pick-up and after light mechanical dressing are of very acceptable appearance.
WELDING AMPERAGE AC and DC
OTHER DATA
Electrodes that have become damp should be re-dried at 110oC for 1 hour
